Can I order samples before a full production run?

Yes. We ship sample sets of any AOLISHENG model so you can validate fit, load and finish before committing to volume. Tell us your cabinet opening width and drawer length and we will match the model.

Do you make custom lengths or mounting holes?

Standard lengths are stocked, and custom lengths, hole patterns and finishes are available for OEM and ODM projects. Share your drawing or dimensions and our engineering team will confirm feasibility.

What is the typical lead time and MOQ?

Stock models ship from our US warehouse in 2 to 5 business days. Production runs for custom or large orders are scheduled per your forecast; minimum order quantities are confirmed when we quote.

Are mounting screws and instructions included?

Each set ships with the matching fixing hardware and a fitment guide. Side-mount and undermount models use standard wood screws; stainless and heavy-duty sets include the heavier fixings they need.

What warranty do AOLISHENG slides carry?

All slides are built from cold-rolled or stainless steel with sealed ball bearings and are covered against manufacturing defects. For your application we will confirm the rated cycle life and warranty terms in writing.

AOLISHENG 100 lb Full Extension Side-Mount Drawer Slides for Kitchen Cabinets – 10 Pairs (A4510) - 45widedrawerslides...

Click to enlarge

AOLISHENG 100 lb Full Extension Side-Mount Drawer Slides for Kitchen Cabinets – 10 Pairs (A4510)

Login to see prices

Weight	N/A

SKU: 7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512 Categories: all-products, Cabinet Drawer Slides, Hot Sales, Side Mount Drawer Slides

📦 US Warehouse🚚 Ships in 2-5 Business Days🏭 Factory-Direct Pricing

Request a Quote

Specifications

Type	45 mm Wide Home & Decor Slide Rail
Material	Q235 Cold-rolled Steel / 201 & 304 Stainless Steel
Mounting	Side-mounted
Load Capacity	35 kg (≈77 lb) standard; up to 45 kg (≈100 lb) in 304 stainless
Width	45 mm
Installation Thickness	12.7 ± 0.3 mm
Material Thickness	1.0 × 1.0 × 1.2 mm (standard); 1.0 × 1.0 × 1.0 mm (stainless)
Surface Treatment	Blue Zinc Plating / Black Electrophoresis
Available Lengths	10 – 24 inch

Specifications and dimensions per ALS 2026 product catalogue.

AOLISHENG 4510 Series Specifications

45MM WIDE HOME & DECOR SLIDE RAIL

Load Capacity	35 kg / 77 lb (standard); 40 kg / 88 lb (anti-tip)
Installation Method	Side-mounted
Width	45 mm
Material	Q235 Cold-rolled Steel / 201 Stainless Steel
Surface Treatment	Blue Zinc Plating / Black Electrophoresis
Material Thickness	1.0 × 1.0 × 1.2 mm
Installation Thickness	12.7 ± 0.3 mm
Available Lengths	8 – 24 inch

Source: Per ALS 2026 catalogue

Available sizes and order codes

Every length below is a stocked variation of AOLISHENG 100 lb Full Extension Side-Mount Drawer Slides for Kitchen Cabinets – 10 Pairs (A4510). Sold as one pair (left plus right). Choose a size to open it with the length pre-selected.

Size	Order code	Availability	Price
10"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size
12"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size
14"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size
16"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size
18"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size
20"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size
22"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size
24"	7368742043828-aolisheng-100lb-kitchen-cabinets-full-extension-side-mount-drawer-slides-a4512	In stock	Login to see prices	View size

Need a length that is not listed? We produce custom lengths and hole patterns for OEM and ODM runs. Send your dimensions for a quote.

Guides for this model

Choosing between series?

Read the drawer slide buying guide for a side-by-side on load rating, extension type, mount style and material, including a quick-pick table by application.

This slide belongs to

Request a quote · Contact AOLISHENG

DIY Wooden Drawer Slides

100 lb Load Capacity | 3-Fold Full Extension | Side Mount | 1 Pair

Product Description

The AOLISHENG DIY Wooden Drawer Slides are designed for smooth, quiet operation and long-lasting durability. The electrophoresis black finish isolates direct contact with water and air, preventing oxidation and rust while enhancing corrosion resistance.

These slides feature a 3-fold full-extension, sturdy ball-bearing design that is detachable for easy installation. Tested by professional institutions, they are rated for over 100,000 open-and-close cycles with a normal service life exceeding 30 years. Quiet and friction-free operation ensures low noise and secure use.

Supports up to 100 lb (45 kg), making them suitable for a wide variety of household and residential drawer applications.

Key Features

Durable & Corrosion-Resistant: Electrophoresis black finish prevents rust and oxidation.
Quiet, Smooth Operation: Ball-bearing system ensures friction-free movement with low noise.
Full Extension & Easy Installation: 3-fold full-extension design allows complete drawer access. Detachable rails simplify installation.
Handle Required: Since the slides pull inward, a handle is needed. For handle-free drawers, use push-to-open slides.
Tested & Long-Lasting: Rated for over 100,000 cycles, with a normal service life of 30+ years.

Installation Guide

Rail Length: 24 in (for drawers with interior depth ≥ 24 in)
Full Extension Length: 48 in (3-section design)
Mounting Clearance: Left 0.5 in, Right 0.5 in
Package Includes: Mounting screws
Installation Tip: Push the inner ball to the top, connect to the main rail, then gently push to complete installation. Keep rails parallel on both sides to ensure smooth operation.
